PEPWAVE MAX HD2 MediaFast (EU) Multi Cellular Router
| หมวดหมู่ | MAX Multi SIM |
| ราคา | 0.00 บาท |
| ยี่ห้อ | PEPWAVE |
| รุ่น | PEP-MAX-HD2-MFA-LTE-E-T |
| สถานะสินค้า | พร้อมส่ง |
| ลงสินค้า | 24 เม.ย. 2561 |
| อัพเดทล่าสุด | 24 เม.ย. 2561 |
| คงเหลือ | ไม่จำกัด |
| จำนวน | pcs |
รายละเอียดสินค้า
The HD2 MediaFast and HD4 MediaFast team up embedded cellular modems and other great features of the HD Series with our MediaFast content caching, which lets you store content for later playback anywhere, regardless of connectivity.
FEATURE :
- Multi-Cellular Bandwidth Bonding Router (6 WAN)
- SpeedFusion Bandwidth/VPN Bonding available separately as a paid upgrade
- 1x USB, 2x Ethernet, Wi-Fi WAN
- 2x Embedded 4G LTE Modem (Global GSM)
- 802.11n Wi-Fi AP
- 120GB SSD
- Full Antenna Set
- PoE Injector Available Separately
Quad 4G LTE Content Caching Router
The HD2 MediaFast and HD4 MediaFast team up embedded cellular modems and other great features of the HD Series with our MediaFast content caching, which lets you store content for later playback anywhere, regardless of connectivity.
Mobile Content Caching
Deliver endless content without consuming endless bandwidth. The MediaFast Editions of the HD2 and HD4 let you download content once and play it back without limit, even in locations where connectivity is spotty or absent.
Dual/Quad Embedded Cellular Modems
The HD2 with MediaFast includes two built-in 4G LTE modems (four on the HD4 with Mediafast). It allows you to use the same or different cellular providers for bandwidth bonding, data overage protection or eliminating blind spots.
List of Supported Carriers
SpeedFusion Bandwidth Bonding and Seamless Failover
SpeedFusion bandwidth bonding technology bonds all connected bandwidth into a single superfast stream, using the same or different cellular providers.
See Demonstration of Unbreakable VoIP
Fleet Tracking and Management
With built-in GPS fleet tracking and InControl 2 cloud-based management, you can keep tabs on location and manage your mobile network from any Internet-connected device.
Customizable Captive Portal
Branding your captive portal is as easy as uploading your logo and terms & conditions. You can easily set bandwidth allowance and access duration per user or manage access using RADIUS server.
With Social Wi-Fi Hotspot support, you can also receive valuable demographic data from your users.
Terminal Block for Secure Power Supply
MAX HD2/HD4 with MediaFast is equipped with a terminal block for secure installation in vehicles and other locations.
PoE Output Option Available
Cut down on cabling and simplify deployments. With a PoE activation kit purchase, the HD2/HD4 with Mediafast supports 802.3at PoE, so one wire is all you need for both connectivity and power.
Model Comparison
| Model | MAX HD2 | MAX HD2 mini | MAX HD4 | MAX HD2/HD4 with MediaFast |
|---|---|---|---|---|
| Product Code | HD2-LTE | HD2-MINI-LTE | HD4-LTE | HD2-MFA-LTE/ HD4-MFA-LTE |
| Ethernet WAN Ports | 2 (GE) | 1 (GE) | 2 (GE) | 2 (GE) |
| Ethernet LAN Ports | 4 (GE) | 2 (GE) | 8 (GE) | 8 (GE) |
| Embedded 4G LTE/3G | 2 | 2 | 4 | 2/4 |
| Redundant SIM Slots |  |
 |
|
|
| SIM Card Size | Mini-SIM (2FF) | Mini-SIM (2FF) | Mini-SIM (2FF) | Mini-SIM (2FF) |
| USB WAN Modem Port | 1 | 1 | 1 | 1 |
| Wi-Fi WAN 1 | |
|
|
|
| Wi-Fi AP 1 | |
|
|
|
| Maximum number of SSID: | 16 | N/A | 16 | 16 |
| Wi-Fi Standard | 802.11ac/a/b/g/n 1166Mbps 2x2 MIMO |
|
802.11ac/a/b/g/n 1166Mbps 2x2 MIMO |
802.11ac/a/b/g/n 1166Mbps 2x2 MIMO |
| Transmit Power (2.4GHz) | 23dBm | |
23dBm | 23dBm |
| Transmit Power (5GHz) | 21dBm | |
21dBm | 21dBm |
| Simultaneous Dual-Band Wi-Fi AP | |
|
|
|
| Recommended Users 2 | 150 | 150 | 500 | 150/500 |
| Router Throughput 3 | 400Mbps | 300Mbps | 400Mbps | 400Mbps |
| LTE Modems | Downlink/Uplink Datarate: 100Mbps/50Mbps | |||
| LTE-A Modems | Downlink/Uplink Datarate: 300Mbps/50Mbps | |||
| Cache Throughput 4 | |
|
|
150Mbps |
| Disk Drive | |
|
|
120GB SSD |
| Core Functionality | ||||
| Drop-in Mode | |
|
|
|
| High Availability | |
|
|
|
| WAN as LAN | |
|
|
|
| Web Blocking | |
|
|
|
| Web Filtering Blacklist | Lite | Lite | Lite | Lite |
| VPN Functionality | ||||
| PepVPN/SpeedFusion Hot Failover | |
|
|
|
| SpeedFusion WAN Smoothing | |
|
|
* |
| SpeedFusion Bandwidth Bonding | |
|
|
* |
| Number of PepVPN SpeedFusion Peers | 2 | 2/20 + | 2/20 + | 2 |
| PepVPN/SpeedFusion Throughput (No Encryption) |
100Mbps | 100Mbps | 150Mbps | 150Mbps |
| PepVPN/SpeedFusion Throughput (256-bit AES) |
60Mbps | 60Mbps | 120Mbps | 120Mbps |
| Central Management | ||||
| InControl Cloud Management | |
|
|
|
| GPS Fleet Management | |
|
|
|
| AP Controller Functionality | ||||
| Manage Pepwave AP Series | |
|
|
|
| Maximum Number of AP Support | 30 | 30 | 30 | 30 |
| Hardware Features | ||||
| Enclosure | Indoor Metal | Compact Indoor Metal | Indoor Metal | Indoor Metal |
| PoE Output | Up to Four 802.3af PoE Outputs # | Up to Two 802.3af PoE Outputs # | Up to Eight 802.3at PoE Outputs # | Up to Eight 802.3at PoE Outputs # |
| Terminal Block Power Connector for Mobile/Vehicular Deployment | |
|
|
|
| Dimensions (Height x Width x Depth) |
1.6 x 10.2 x 5.6 inches 40 x 260 x 143 mm |
1.6 x 5.8 x 5 inches 40 x 147 x 128 mm |
1.9 x 11.5 x 6.9 inches 50 x 292 x 177 mm |
1.9 x 11.5 x 6.9 inches 50 x 292 x 177 mm |
| Weight | 2.2 pounds 1 kg |
0.96 pounds 0.5 kg |
4.20 pounds 1.9 kg |
4.20 pounds 1.9 kg |
| Operations | ||||
| AC Adapter | AC Input 100V - 240V DC Output 12V or 48V, 3A |
AC Input 100V - 240V DC Output 12V or 48V, 2A |
AC Input 100V - 240V DC Output 12V or 56V, 4A |
AC Input 100V - 240V DC Output 12V or 56V, 4A |
| Power Input | DC 12V - 48V, 3A | DC 12V - 48V, 2A | DC 12V - 56V, 4A | DC 12V - 56V, 4A |
| Terminal Block | DC 12V - 48V, 3A | DC 12V - 48V, 2A | DC 12V - 56V, 4A | DC 12V - 56V, 4A |
| Power Consumption | 28W (max.) | 15W (max.) | 38W (max.) | 38W (max.) |
| Operating Temperature | -40° - 149°F -40° - 65°C |
-40° - 149°F -40° - 65°C |
-40° - 149°F -40° - 65°C |
-40° - 149°F -40° - 65°C |
| Humidity | 15% - 95% (non-condensing) | |||
| Certifications | ||||
| FCC, CE, RoHS | |
|
|
|
| RF Port Lightning Immunity: ITU-T K.20 (+/- 1.5 kV) |
|
|
|
|
| Certifications - Carrier | ||||
| Verizon | |
|
|
|
| Sprint | |
|
|
|
| Certifications - Motor Vehicle | ||||
| E-Mark | |
|
|
|
| Certifications - Rolling Stock | ||||
| EN 61373:2010 Shock and Vibration Resistance |
|
|
|
|
| EN 50155 Railway Applications - Electronic Equipment used on Rolling Stock |
|
|
|
|
| EN 61000 Electromagnetic Compatibility |
|
|
|
|
| Warranty | 1-Year Limited Warranty | |||
